Get the cheapest parallel export price, we will reply you within 24 hours.
It adopts advanced S-type poppet valve reversing technology, which can meet the transportation of fine aggregate concrete. The spectacle plate and cutting ring are made of high-hardness wear-resistant alloy material, ensuring a longer service life. The imported main oil pump provides high outlet pressure, meeting the transportation needs of high-rise buildings and long-distance construction.
The hydraulic oil cooling system uses air cooling, providing good cooling effect and ease of use; it has a reverse pumping function, minimizing pipe blockage even with poor concrete slump. Equipped with a centralized lubrication system, lubricating oil is distributed to all parts, ensuring the service life of rotating components; the electrical box uses Mitsubishi electrical components and is equipped with a wireless remote control handle, ensuring stable and easy operation.
|
Power type |
diesel fuel |
|
country of origin |
Henan, China |
|
Warranty period |
12 months |
|
Dimensions (length x width x height) |
4960mm * 2100mm * 2600mm (meters) |
|
Product Name |
Widely used in JBT30 diesel engine concrete mixers with pumps for sale |
|
Delivery height |
70m |
|
Maximum aggregate size |
40 meters |
|
Remote control |
Wired remote control |
|
Conveyor cylinder diameter |
200 Tongmi |
|
Warranty |
12 months |
|
brand |
HAMAC |
|
Power (W) |
52kW |
|
weight |
5300 kg |
|
Provide after-sales service |
Engineers can work overseas |
|
concrete mixer |
JZM450 |
|
Conveying distance |
300m |
|
main oil pump |
Kawasaki |
|
Pump type |
S valve |
|
Pump capacity |
40 cubic meters/h |
|
Certification |
ISO9001 |
