The Dongfeng Chaolong EQ6850CHTN Bus (Natural Gas, China V Emission Standard, 10-31 Seats) is a natural gas-powered bus that meets China V emission standards. It is 8.49 meters long, 2.5 meters wide, and has optional heights of 2.98, 3.19, or 3.34 meters. It has a curb weight of 8.2 tons and a gross vehicle weight of 12.2 tons. It features a semi-unibody structure and a top speed of 69 km/h.
Powertrain: Equipped with the Guangxi Yuchai YC4G180N-50 engine, with a displacement of 5.2L and a power of 132kW, meeting China V emission standards.
Seating Layout: Flexible seating configurations are available, ranging from 10 to 31 seats. Standard bus seats (25+1) are standard, and an MP3 player or hard drive player is optional.
Comfort: Optional Dongfeng Pine roof-mounted air conditioning (26kW), electric wipers, a variable-speed defroster (24V, 170W), and combination front and rear round headlights are available.
Standard electric wipers and standard long round headlights are included. The reinforced semi-load-bearing design of the vehicle body structure balances lightweightness and stability.
The Dongfeng Chaolong EQ6850CHTN bus (natural gas National V standard, 10-31 seats) offers multiple height options (2.98-3.34 meters) to accommodate various operating scenarios (such as roof-mounted air conditioning or gas cylinder installation). The powertrain is highly efficient and energy-efficient, and natural gas fuel reduces operating costs while meeting environmental requirements.
|
Vehicle parameters/information |
|
|
Announcement Model |
EQ6850CHTN |
|
use |
Public buses |
|
Body length |
8490mm |
|
Body width |
2500mm |
|
Ride height |
2980,3190,3340mm |
|
Vehicle quality |
8200kg |
|
Total mass |
12200kg |
|
Body structure |
Semi-loaded |
|
Number of seats |
10-31 |
|
Maximum speed |
69km/h |
|
Air conditioning system |
Optional Dongfeng Pine roof-mounted air conditioner 26KW |
|
Audiovisual system |
MP3 player; hard disk player optional |
|
Auxiliary configuration |
Standard bus seats (25+1); double-wiping electric wipers; new front and rear round light combination, standard long dome light; gear shift defroster 24V 170W |
|
Engine/motor parameters |
|
|
engine |
YC4G180N-50 |
|
Engine power |
132kW |
|
displacement |
5200mL |
|
Engine brand |
Guangxi Yuchai Machinery Co., Ltd. |
|
Emission standards |
GB17691-2005 National V, GB18285-2005, GB11340-2005 |
|
Chassis parameters/configuration |
|
|
Chassis model |
EQ6820HN5AC Class III Dongfeng Motor Corporation |
|
Front and rear suspension |
1900/2590mm |
|
Number of springs |
8/9 |
|
gearbox |
QJ705 |
|
clutch |
Single-piece dry diaphragm spring Ф395 |
|
Number of axes |
2 |
|
wheelbase |
4000mm |
|
Axle load |
4200/8000kg |
|
Front track |
2020mm |
|
rear track |
1800mm |
|
Approach departure angle |
8/8° |
|
tire |
|
|
Number of tires |
6 |
|
Specification |
8.25R20,8.25-20,9R22.5 |
