The Dongfeng Chaolong EQ6752LTV Bus (National V Diesel, 24-31 Seats) is a medium-sized diesel bus under Dongfeng Chaolong. Designed for passenger transport, tourism, and group travel, it features a diesel powertrain that meets the National V emission standards, balancing power and operating economy, making it suitable for medium- and short-distance passenger transport.
Dimensions: Length 7480mm, Width 2360mm, Height 2950mm (standard version) or 3160mm (air-conditioned version), Wheelbase 3800mm, Vehicle Weight 5380-5580kg, Gross Vehicle Weight 8000kg.
Powertrain: Equipped with a Weichai WP4.1Q140E50 or Yuchai YC4S series diesel engine, offering 103-110 kW, 3.8-4.1 L displacement, a top speed of 100 km/h, and emissions that meet the National V standard (GB17691-2005).
Seating: Flexible seating configurations from 24 to 31 seats, with a standard 25-seat standard seating configuration (2+2 layout) and an optional shock-absorbing driver's seat.
Safety: Standard ABS (Guangzhou Ruili Komi CM4XL-4S/4K), a satellite-based driving recorder, emergency door entry, and seatbelts throughout the vehicle. The vehicle has undergone multiple safety certifications.
Comfort: Optional roof-mounted air conditioning (vehicle height 3160 mm) and an MP3 player with USB/SD card slots are available. Electric wipers, a 24V 170W gear-shift defroster, and a half-width sunshade are standard.
The Dongfeng Chaolong EQ6752LTV bus (diesel National V 24-31 seats) is suitable for urban bus shuttles, tourist group transportation and corporate commuting. Its diesel power design can adapt to high-intensity operation needs.
|
Vehicle parameters/information |
|
|
Announcement Model |
EQ6752LTV |
|
use |
Passenger bus, tourist bus, group bus |
|
Body length |
7480mm |
|
Body width |
2360mm |
|
Ride height |
2950,3160mm |
|
Vehicle quality |
5380,5580kg |
|
Total mass |
8000kg |
|
Body structure |
Non-load-bearing |
|
Number of seats |
24-31 |
|
Maximum speed |
100km/h |
|
Air conditioning system |
electric fan |
|
Audiovisual system |
MP3 player (with USB port and SD card port) |
|
Auxiliary configuration |
24V, 170W gearshift defroster; 2+2 layout, 25-passenger seat, standard seats, shock-absorbing driver's seat; electric wipers; front and rear combination headlights, high-mounted brake light; engine speed limit: 99 km/h; colorful floor coverings, high and low floors, lowered rear compartment, half-width roll-up sunshade, one fire extinguisher (4 kg), two safety hammers, seat belts for all vehicles, DC816A sunroof, air horn, electronic clock with temperature display, mechanical power switch |
|
Engine/motor parameters |
|
|
engine |
WP4.1Q140E50,YC4S140-50,YC4S150-50 |
|
Engine power |
103,103,110kW |
|
displacement |
4088,3767,3767mL |
|
Engine brand |
Weichai Power Yangzhou Diesel Engine Co., Ltd., Guangxi Yuchai Machinery Co., Ltd., Guangxi Yuchai Machinery Co., Ltd. |
|
Emission standards |
GB17691-2005 National V, GB3847-2005 |
|
Chassis parameters/configuration |
|
|
Chassis model |
EQ6690K5AC Class III Dongfeng Motor Corporation |
|
Front and rear suspension |
1280/2400mm |
|
Number of springs |
9/11 |
|
gearbox |
JK5S550 |
|
clutch |
Diaphragm spring |
|
Number of axes |
2 |
|
wheelbase |
3800mm |
|
Axle load |
3000/5000kg |
|
Front track |
1830mm |
|
rear track |
1628,1670mm |
|
Approach departure angle |
18/12° |
|
tire |
|
|
Number of tires |
6 |
|
Specification |
8.25-16,8.25R16,8.25-16LT,8.25R16LT,9.5R17.5 |
