Dongfeng Chaolong EQ6750ST6D Preschool School Bus (China VI Diesel, 24-44 Seats)
The Dongfeng Chaolong EQ6750ST6D Preschool School Bus (China VI Diesel, 24-44 Seats) is designed specifically for children and meets China VI emission standards. It has a length of 7535mm, a width of 2400mm, and a height of 2900mm or 3050mm (air-conditioned version). The vehicle utilizes a high-strength steel structure and is equipped with the Guangxi Yuchai YCY24140-60 engine, which complies with the China VI emission standards of GB3847-2005 and GB17691-2018. It boasts a maximum power of 103kW and a displacement of 2360ml, with a maximum speed limit of 80km/h.
Core Features
Safety Features: Standard ABS (manufactured by Guangzhou Ruili Komi), engine ECU speed limiter, and a satellite positioning driving recorder.
Flexible Options: Supports 360-degree surround view system, various side window styles, and school bus logos. The air-conditioned version has a height increase of 3050mm.
Chassis Design: Wheelbase 4200mm, front overhang 970mm/rear overhang 2365mm, tire size 215/75R17.5, axle load distribution 2600/4650kg.
The Dongfeng Chaolong EQ6750ST6D preschool school bus (diesel National VI 24-44 seats) is suitable for kindergartens and educational institutions, offering 24-44 seats to meet group transportation needs. Its optimized dimensions balance passability and passenger capacity, and its diesel engine ensures long driving range.
|
Vehicle parameters/information
|
|
Announcement Model
|
EQ6750ST6D
|
|
use
|
school bus
|
|
Body length
|
7535mm
|
|
Body width
|
2400mm
|
|
Ride height
|
2900,3050mm
|
|
Vehicle quality
|
5030,5190kg
|
|
Total mass
|
7250kg
|
|
Number of seats
|
24-44
|
|
Maximum speed
|
80km/h
|
|
Engine/motor parameters
|
|
engine
|
YCY24140-60
|
|
Engine power
|
103kW
|
|
displacement
|
2360mL
|
|
Engine brand
|
Guangxi Yuchai Machinery Co., Ltd.
|
|
Emission standards
|
GB3847-2005, GB17691-2018 Country VI
|
|
Chassis parameters/configuration
|
|
Chassis model
|
EQ6720KS6T Class III Dongfeng Special Automobile Co., Ltd.
|
|
Front and rear suspension
|
970/2365mm
|
|
Number of springs
|
24-44
|
|
Number of axes
|
2
|
|
wheelbase
|
4200mm
|
|
Axle load
|
2600/4650kg
|
|
Front track
|
1835mm
|
|
rear track
|
1670mm
|
|
Approach departure angle
|
17/9°
|
|
tire
|
|
Number of tires
|
6
|
|
Specification
|
215/75R17.5
|
