Dongfeng Chaolong EQ6586WACDB bus (diesel National VI standard, 10-15 seats)

Dongfeng Chaolong EQ6586WACDB Bus (Diesel China VI, 10-15 Seaters)

The Dongfeng Chaolong EQ6586WACDB is a diesel-powered medium-sized bus that meets China VI emission standards. It has a length of 5.58 meters, a width of 2.09 meters, and a height of 2.415-2.7 meters (with optional mid-roof or high-roof options). It has a curb weight of 2.71 tons and a gross vehicle weight of 4.495 tons. It has a rated capacity of 10-15 passengers. It is equipped with a Foton Cummins F2.8NS6B177L diesel engine with a displacement of 2.78 liters and a maximum power of 130 kW. It is mated to a 6-speed manual transmission and has a top speed of 140 km/h (100 km/h with the optional speed limiter). It meets the GB17691-2018 China VI emission standard.

Body Configuration

The vehicle features a monocoque design with a 3.35-meter wheelbase and front and rear overhangs of 993/1392 mm (long-wheelbase version). It is equipped with 2/4/5-leaf spring suspension, 195/75R16LT tires, and an axle load distribution of 1950/2545 kg. Safety features include the Wuhan Yuanfeng ABS system (model YF8), a satellite-based driving recorder, and an optional speed limiter. The braking system utilizes a dual-circuit air brake system.

Vehicle Features

This vehicle is suitable for passenger transport, tourism, and group commuting. Optional features include power sliding doors, 270-degree rear doors, parking sensors, and a high roof (2.7 meters high). Customizable side window structures and scuff strips are available. Its flexible body size (available in wheelbases ranging from 5.49 to 5.735 meters) and high-powered 130 kW engine provide a balance of urban maneuverability and passenger efficiency, making it a practical choice for corporate shuttles and scenic area shuttles.
