Dongfeng Chaolong EQ5091XXYTV Van Transporter (Diesel National V Emission Standard, 2-6 Seaters)
Vehicle Positioning and Compliance
Yellow-Plate Cargo: With a total length of 7.48 meters and a rated load capacity of 3.77 tons, it is suitable for intercity trunk logistics and bulk cargo transport.
Powertrain: Equipped with a Yuchai YC4S140-50 diesel engine with a maximum horsepower of 140, paired with a 5-speed transmission, it has a top speed of 95 km/h and meets the National V emission standards.
Cargo Capacity and Design
Cargo Box Volume: The enclosed cargo box has interior dimensions of 6.1 meters x 2.35 meters x 2.35 meters, with a volume of approximately 33.6 cubic meters. It supports skeleton-type pull-tabs for cargo securement.
Driving Comfort: Featuring a bus-like design, it features knitted fabric airbag seats with shock-absorbing cushioning, an air brake system, and a spacious cab with optional blackout curtains for the rear seats.
Safety and Scalability
Protective Design: The independent passenger-side guard plate houses the fuel tank and urea tank, reducing the risk of scratches and damage. The modular taillight design allows for individual replacement, reducing maintenance costs.
Travelability: The front track is 1830mm, and the rear track is 1628mm, adaptable to various complex road conditions.
The Dongfeng Chaolong EQ5091XXYTV van (diesel National V standard, 2-6 seats) features high load capacity, large volume, and adaptability to trunk line transport, making it suitable for logistics companies with high transport capacity requirements.
|
Vehicle parameters/information
|
|
Announcement Model
|
EQ5091XXYTV
|
|
use
|
Special passenger car
|
|
Body length
|
7480mm
|
|
Body width
|
2360mm
|
|
Ride height
|
2950,3160mm
|
|
Vehicle quality
|
5100kg
|
|
Total mass
|
9000kg
|
|
Number of seats
|
2,2+2,2+3,2+4
|
|
Maximum speed
|
95km/h
|
|
Engine/motor parameters
|
|
engine
|
WP4.1Q140E50,YC4S140-50
|
|
Engine power
|
103,103kW
|
|
displacement
|
4088,3767mL
|
|
Engine brand
|
Weichai Power Yangzhou Diesel Engine Co., Ltd., Guangxi Yuchai Machinery Co., Ltd.
|
|
Emission standards
|
GB17691-2005 National V, GB3847-2005
|
|
Chassis parameters/configuration
|
|
Chassis model
|
EQ6690KZ5AC Class III Dongfeng Motor Corporation
|
|
Front and rear suspension
|
1280/2400mm
|
|
Number of springs
|
9/11+5
|
|
Number of axes
|
2
|
|
wheelbase
|
3800mm
|
|
Axle load
|
3000/6000kg
|
|
Front track
|
1830mm
|
|
rear track
|
1628mm
|
|
Approach departure angle
|
18/12°
|
|
tire
|
|
Number of tires
|
6
|
|
Specification
|
8.25-16,8.25R16,8.25-16LT 14PR,8.25R16LT 14PR
|
