Ankai HFF6109K10PHEV-11 plug-in bus (diesel/electric hybrid, National V standard, 24-51 seats)

Ankai HFF6109K10PHEV-11 Plug-in Bus (Diesel/Electric Hybrid, China V Emission Standard, 24-51 Seats)

The Ankai HFF6109K10PHEV-11 hybrid bus is a versatile solution. The 2025 model year HFF6109K10PHEV-11 is a plug-in hybrid model designed by Ankai Bus for medium- and long-distance passenger transport and group travel, offering flexible configurations of 24-51 seats. The vehicle utilizes a diesel and electric hybrid dual-mode drive system, boasting a combined range exceeding 800 kilometers under CLTC conditions. It supports fast charging and intelligent energy management, achieving the dual goals of efficient operation and environmentally friendly travel.

Technical Highlights

The dual-source powertrain features a Yuchai YC6A270-50 diesel engine (199kW) and a permanent magnet synchronous motor, delivering a total system power of 320kW. Its unique intelligent torque distribution technology enables a pure electric range of 100 kilometers, while fuel consumption in hybrid mode is 30% lower than conventional models.

Intelligent Energy Management

Equipped with a 50kWh lithium manganese oxide battery pack, it supports fast charging in 1.5 hours (SOC 0-80%). Braking energy regeneration efficiency has been increased to 85%, significantly reducing operating costs.

Safe and Comfortable Architecture

The high-strength steel body is rollover-certified and comes standard with ABS anti-lock braking system and lane departure warning. The six-airbag air suspension automatically adjusts vehicle height based on load, enhancing passenger comfort.

Vehicle Configuration

The Standard Passenger Edition (24-32 seats) features a 2+2 seating layout and is equipped with pneumatic swing doors and manual emergency exits. Higher-end models can be equipped with optional water dispensers and luxurious interior features, meeting the high-end travel needs of tour groups.

The Custom Commuter Edition (33-51 seats) offers enhanced standing room (capacity up to 120 passengers), non-slip handrails, and a large luggage rack. Optional rearview camera and blind spot monitoring systems enhance safety in complex road conditions.

The vehicle has passed 500,000 km of high-altitude and cold-weather testing, boasting a 5,120mm wheelbase for enhanced cornering flexibility. It supports V2G vehicle-to-grid interaction, providing reverse power during off-peak hours, reducing overall operating costs by 25%. Its three-electric system comes with an extended 8-year/500,000 km warranty, making it an ideal choice for upgrading green passenger transport.
