Rear-dump semi-trailers are specialized trailers designed for transporting and unloading various bulk materials such as sand, gravel, coal, and construction materials. The main feature of these semi-trailers is their rear unloading function. This design allows goods to be unloaded from the rear of the trailer, enabling quick unloading and loading. This significantly improves loading efficiency, saving time and labor. Some rear-dump semi-trailers are also equipped with a hydraulic system for more precise and controlled unloading. The advantages of this type of semi-trailer lie in its large carrying capacity, efficiency, and versatility. It can operate on various roads and terrains and adapt to different working environments.
These dump trailers, also known as rear-dump trailers, operate by unloading cargo from the rear of the vehicle. They are commonly used to transport loose materials such as aggregates, sand, gravel, and construction waste, and are widely used in construction, mining, agriculture, waste management, landscaping, and excavation industries.
|
type |
semi-trailer |
|
brand |
Oem |
|
Compatible vehicle types |
Truck trailer |
|
size |
13000*2500*4300 |
|
axle |
zy/ 13/14/16 tons |
|
suspension |
Single-point suspension |
|
tire |
11.00R20/12.00R20/12R22.5 |
|
landing gear |
28t*2, JOST brand |
|
Spray paint |
Sand cultivation |
|
Maximum load |
40-50T |
|
Material |
steel |
|
Product Name |
Dump truck trailer |
|
Main beam |
T700/Q345 steel, height: 500mm, plate thickness: 8-16mm |
|
condition |
New |
|
Brake chamber |
6 sets |
|
Electrical system |
24V, one set of 6-core standard cables |
|
country of origin |
|
|
Single package size |
Truck trailer |
|
Gross weight of a single product |
10,500,000 kg |
|
Overall dimensions |
11000*2500*4300 mm or custom sizes |
|
curb weight |
6.5T |
|
Load capacity |
40T, 50T, 60T, 70T, 80T, 90T, 100T |
|
Main beam specifications. |
T700/Q345 steel, height: 500 mm, plate thickness: 8-16 mm |
|
Side frame |
Channel steel |
|
Cross bracket |
Channel steel/bent steel |
|
suspension |
Mechanical suspension, air suspension or optional |
|
leaf springs |
10-layer leaf springs (90mm * 13mm * 10pcs) |
|
Axle specifications. |
13T/16T/20T BPW or FUWA brand |
|
Main sales |
2" (50 mm) or 3.5" (90 mm) JOST brand |
|
tire |
11.00R20/12.00R20/12R22.5 |
|
Braking chamber |
6 sets |
|
landing gear |
28T * 2, JOST brand |
|
appendix |
1 standard toolbox |
|
Electrical system |
24V, a set of 6-core standard cables |
|
Light |
Taillights with turn signals, brake lights and reflectors, side lights, etc. |
|
painting |
Packing machine, primer, surface paint, colored opium, wax polishing |
|
ladder |
Spring or hydraulic |
|
Package |
Full container load (FCL), roll-on/roll-off (Ro-Ro), flat rack, or optional |
